Technical data
-
Volume
45 m3
-
Type of equipment
tank semi-trailer (fuel tanker)
-
Bulb shape
cylinder of variable cross-section
(bottle shape) -
Curb weight
from 8,700 kg -
Overall dimensions
length: 12,700 mm
width: 2,550 mm
height: 3,750 mm -
Number of sections
Section 1: 10.9 m3
Section 2: 10.9 m3
Section 3: 10.9 m3
Section 4: 12.3 m3
The volumes of the sections are listed in order from the fifth-wheel coupling. -
Fifth-wheel coupling height
1,150 mm -
Number of axes
3 axes
-
Suspension and tires
- 3 axes;
- drum/disc type brake mechanisms;
- tires (at the discretion of the manufacturer) with a dimension of 385/65 R22.5 with a disc - 6 + 1 pcs.
-
Painting
THE SEMI-TRAILER IS PAINTED ACCORDING TO THE PROPRIETARY THREE-STAGE PAINTING SYSTEM "PRIME SYSTEM":
- surface treatment in a shot blasting chamber;
- coating with a primer containing anticorrosive elements;
- painting with premium enamel.
-
Brake system
pneumatic two-circuit. -
Electrical equipment
electrical equipment Aspoeck / Hella / Ermax or similar.
